Inner and outer Tea Bag Packaging Machine By Autompack Packaging

Application:

Suitable for the non-returnable packaging of the inner and outer bag of small particulate materials with automation precision volumetric Cups equipment, such as tea, herbal tea, health tea grass-root type, green tea, black tea, scented tea, coffee,health tea, herbal tea and so on.

Sealing Type: Three sides sealing

Features:

1. Inner and outer bag's film drawing is controlled by the stepper motor, stable bag length and accurate positioning.

2. The temperature controller is adjusted by PID to make the temperature control more accurate.

3. Overall machine movement is controlled by PLC, with human-machine interface display, ensure health of products.

4. Packing material：filter paper, thread, composite membrane and labels.

Technical Parameters:

Measuring Scope: 3 - 10 g(1.6 ~ 26 ml);

Inner bag size: ( L ): 50 - 70 mm   ( W ): 45 - 80 mm ;

Outer bag size:(L): 80 - 120mm   ( W ): 75 - 95 mm;

Packing Speed: 30-40 bags / min;

Dimension ( L*W*H ): 1750*740*1950mm;

Weight: 550 kg;

Total Power: AC220V/ 50Hz /3.7kw;

Gas source: ≥0.4m³/min.
