Inquiry:
Candy and Nuts
Automatic Premade Pouch Small Hard And Soft Candy Packaging Machine
- Advantages: This is our Autompack automatic rce sugar dried stand up pouch doypack filling and packing machine. Doy packing bag is more and more popular in European and USA market. It is more conveni
- Guarantee: The manufacturer guarantees each machine's electronic, mechanical and pneumatic systems for 1 year.
- Packing speed: 20-60 bags/min
- Packaging Material: Pre-formed Bags
- Description: Hard candy packaging machine, Pouch Candy Packaging Machine, Premade Pouch Candy Packing Machine
Model: ATM-8200W/ 8250W/ 8300W
This is Automatic Premade Pouch Small Hard And Soft Candy Packaging Machine. Doybag is more and more popular in European and USA market. It is more convenient to keep or save the food only need to zip the bag up.
Application:
Suitable for automatic packing for liquid, such as disinfectant, liquid soap, alcohol disinfectant, hand sanitizer etc. Different kinds of product with stand up pouches, doypack with zipper, 3 side seal bags, 4 side seal bags, flat bags, pouch with hole, spout pouch, etc.
Pouch Type:
All type of heat sealable preformed side seal bags, fin seal bags, gusseted bags, block bottom bags, zip-lock recloseable bags, stand-up pouch with or without spout etc.
Features:
1. Automatic rotary packing machine adopt precision indexing device and PLC to control each action and working station to make sure the machine operates easily and does accurately.
2. The speed of this machine is adjusted by frequency conversion with the range, and the actual speed depends on type of products and pouch.
3. Automatic checking system can check bag situation, filling and sealing situation.
4. The system shows:1.no bag feeding, no filling and no sealing; 2.no bag opening/opening error, no filling and no sealing; 3.no filling, no seal.
Technical Characteristics:
|
Model |
ATM-8200W |
ATM-8250W |
ATM-8300W |
|
Packing material |
Pre-made bags, Stand-up bag, Four-side sealed bag, Self-reliance bag, Handbag, Spout bags, Zipper bags, Compound bag, Special-shaped bag etc. |
||
|
Bag size |
(L)100-300mm (W)70-200mm |
(L)100-350mm (W)130-250mm |
(L)150-450mm (W)200-300mm |
|
Filling range |
10g-1000g |
10g-2000g |
10g-3000g |
|
Packing speed |
40-60bag/min (depending on the quality of the packaging film, packaging materials, packaging weight etc.) |
||
|
Measurement Average precision |
≤±0.5-1% (Depending on the measurement on the measurement equipment and materials) |
||
|
Maximum Bag Width |
200mm |
250mm |
300mm |
|
Total power |
1.5KW 380V 50/60hz |
1.8KW 380V 50/60hz |
2KW 380V 50/60hz |
|
Gas Consumption |
0.8Mpa 0.3m3/min |
0.8Mpa 0.3m3/min |
0.8Mpa 0.3m3/min |
|
Air Compressor |
Not less than 1 CBM |
Not less than 1 CBM |
Not less than 1 CBM |
|
Working flow |
giving bag→coding→opening→filling 1→filling 2→auxiliary→exhaust→heat sealing→forming and output product |
||
|
Dimensions |
(L*W*H)1900mm*1400mm*1450mm |
(L*W*H)1900mm*1400mm*1450mm |
(L*W*H)1900mm*1500mm*1550mm |
|
Machine Weight |
1300kg |
1400kg |
1500kg |
