AAutomatic-Multi-Function-Zip-lock-Doypack-And-Stand-Up-Pouch-Food-Granule-Nuts-Packing-Machine

FuApplication: Automatic premade pouch bagger, featured with rapid reaction, reliability and quick changeover, is ideal for a large variety of bag types and range. Equipped with combination weigher and elevator, it is widely applied to different kinds of granular, grains, Nuts, seeds etc.

MModels and Processes：ATM-8200 series premade pouch bagger can be clarified into 8 working stations and 6 working stations in terms of station amounts in one machine. Specifically, the whole processes are involved in the following stations:

1- ➣Pouch-picking Station (Required)

2- ➣Date-printing Station  (Required)

3- ➣Pouch-opening Station (Required)

4- ➣Material-filling Station-1 (Required)

5- ➣Material-filling Station-2 (Optional)

6- ➣Air-exhausting Station  (Optional)

7- ➣Material-detecting Station (Optional)

8- ➣Sealing and Outputting Station (Required)

Process Map for Baggers with 8 Working Stations:

Notes: Required Station is necessary to complete the package. Optional Station is made as per customer’s request, such as zipper-opening device, dual dosing systems, dual sealing configurations, gas flushing device, air exhausting device, and so on.

Pouch Type:

All type of heat sealable preformed side seal bags, fin seal bags, gusseted bags, block bottom bags, zip-lock recloseable bags, stand-up pouch with or without spout etc.

According to the picture you provided, you have to choose 8 working stations:

Technical Parameters:

Model	ATM-8200W
Packing material	Pre-made bags, Stand-up bag, Four-side sealed bag, Self-reliance bag, Handbag, Spout bags, Zipper bags, Compound bag, Special-shaped bag etc.
Bag size	(L)100-300mm  (W)70-200mm
Filling range	10g-1000g
Packing speed	40-60bag/min (depending on the quality of the packaging film, packaging materials, packaging weight etc.)
Measurement Average precision	≤±0.5-1% (Depending on the measurement on the measurement equipment and materials)
Maximum Bag Width	200mm
Total power	1.5KW 380V 50/60hz
Gas Consumption	0.8Mpa 0.3m3/min
Air Compressor	Not less than 1 CBM
Working flow	giving bag→coding→opening→filling 1→filling 2→auxiliary→exhaust→heat sealing→forming and output product
Dimensions	(L*W*H)1900mm*1400mm*1450mm
Machine Weight	1300kg
